Main Features
• 1/4” Sony Super HAD Color CCD for Superior Image Quality
• High Resolution Support
• Excellent Night View(0.1Lux)
• Full Waterproof (IP68) & Die-casting Housing
• Normal or Mirror Image View Support
General Specification
- Image Sensor : 1/4” Sony Super HAD Color CCD
- Pixels : NTSC:270,000/PAL:320,000
- Resolution : 420 TV Lines
- Field of View : 160°
- Sync. System : Internal
- Video Output : 75Ω 1.0Vp-p Composite
- S/N : more than 48dB
- illuminaton : 0.1Lux at F2.0/f=2.9mm
- Operating Temp. : -30°C ~ 60°C
- Storing Temp. : -50°C ~ 60°C
- Power : DC12V/90mA max.
- Powered from Monitor
- Size : 38(W) x 15(H) x 30(D)/mm
1.49”(W) x 0.58”(H) x 1.18”(D)
- Weight : 45g
